Overview

Official PN：781687-01（销售物料 PN）、151831-01L（内部装配 PN），市场简称 TB-2630

NI TB‑2630 is a fully shielded snap-on front terminal breakout accessory only compatible with NI PXI‑2530B 128-channel reed relay multiplexer (incompatible with non-B PXI‑2530). Integrated internal fixed routing enables instant switching of multiple multiplex topologies: 1-wire 128×1 / dual 64×1 / quad 32×1; 2-wire 64×1 / dual 32×1; 4-wire 32×1 / dual 16×1 and independent channel mode. It adopts internal ribbon cable headers for signal distribution plus separate screw terminals for external trigger I/O. Full metal shielding suppresses EMI and channel crosstalk, ultra-low internal trace resistance guarantees high-precision micro-ohm measurement for resistors, RTDs and strain gauges. Mechanical key lock prevents misplugging, RoHS compliant, fully supported by NI‑DAQmx and LabVIEW automated test systems for multi-channel batch parametric inspection.

Core Specifications

Compatible Hardware: PXI‑2530B 128-channel reed relay multiplexer switch only
Configurable Topologies: Rich 1/2/4-wire multiplex layouts split from 16-channel base banks
Interface Structure: Internal ribbon routing headers, independent analog & trigger screw terminals
EMI Performance: Enclosed metal shield housing to eliminate industrial electromagnetic interference
Electrical Rating: Max 60 VDC signal input, minimal internal trace resistance for low-level sensing
Installation: Direct front snap mounting with anti-misplug mechanical interlock
Software Compatibility: Native NI‑DAQmx driver, LabVIEW switch routing automation VIs

Application Scenarios

Passive component multi-channel batch resistance/capacitance testing, RTD multi-point temperature scanning, load cell low-resistance strain measurement, semiconductor leakage screening, university multi-channel switching measurement labs.

Standard Package Contents

TB-2630B shielded terminal block, topology wiring diagram, installation quick guide, safety compliance datasheet.
