Overview

Official PN：782536-01NI

NI SCB‑68A is a shielded 68‑pin screw terminal breakout box upgraded from legacy SCB‑68, designed for NI 68‑pin multifunction DAQ boards (M/X/E Series PCI/PXI/USB DAQ). It converts 68‑pin D‑SUB interface to accessible screw terminals for sensor wiring, matched with shielded cables to suppress EMI and reduce measurement noise. Key built‑in features: magnetic removable cover, DIN rail & panel mounting brackets, 1.1A self-resetting fuse for overcurrent protection, two prototype breadboard zones, and integrated cold-junction compensation (CJC) temperature sensor for thermocouple tests. Supports wire gauges 14–30 AWG, compatible with single/dual 68‑pin DAQ devices, widely deployed for voltage, thermocouple, RTD and strain measurement in labs and industrial test benches.

Core Specifications

Interface: 68-pin female D-SUB to 68-position screw terminal block
Wiring Spec: 14–30 AWG wires, screw torque 0.5–0.6 N·mNI
Safety Circuit: 1.1 A self-resetting non-replaceable fuse, max 60 VDC signal limit
Built-in Functions: Onboard CJC sensor, dual breadboard prototype areasNI
Mounting: Desktop, DIN rail, flat panel mounting compatible
Operating Temp: 0~70 ℃ operating, -20~70 ℃ storage
Compatibility: All NI 68-pin M / X / E Series multifunction DAQ cards

Application Scenarios

Laboratory multi-channel thermocouple temperature logging, strain gauge & load cell static/dynamic testing, industrial low-voltage analog signal acquisition, automotive component bench DAQ measurement, university multifunction data acquisition teaching labs.

Standard Package Contents

SCB-68A shielded terminal box, DIN rail mounting clip, wiring pinout sticker, user manual, safety datasheet.
