Overview

NI PXIe-8398 is single-slot 3U Gen3 MXI-Express x16 remote control module, the latest high-bandwidth remote extension hardware for PXIe chassis. It occupies one PXIe system slot with four external MXI ports, delivering up to 16 GB/s bidirectional total throughput to connect external host PC or master PXI chassis via PCIe-8398 host adapter cardNI. Supports copper cables up to 3m and fiber optic cables up to 100m for long-distance isolation layout; compatible with daisy-chain & star topology to expand multiple PXIe chassis in one test systemNI. The link is fully software-transparent, all PXIe DAQ, SMU, digitizer, RF VST instruments can be directly identified in NI MAX without extra programming. Equipped with PWR/LINK status LED, supports peer-to-peer data streaming and multi-chassis synchronous trigger clock sharing. RoHS compliant, widely used for separated control room test benches, radar/wireless RF high-speed data streaming and multi-chassis semiconductor ATE systems.

Core Specifications

Bus Standard: MXI-Express Gen3 x16, max 16 GB/s full-duplex bandwidth
External Ports: 4 × MXI-Express x8 external ports
Cable Support: Copper (3m max); Fiber (100m max)
System Topology: Daisy-chain, star, tree multi-chassis expansion
Software Feature: Transparent PCIe link, peer-to-peer streaming, shared trigger clock
Form Factor: Single-slot 3U PXIe module, operating temp 0~55℃
Matching Hardware: PCIe-8398 host card, PXIe-8394 bus expander, PXIe-8399 dual-port controller

Application Scenarios

Isolated control room remote PXI test systems, radar & wireless communication RF high-speed data acquisition, multi-chassis mixed-signal semiconductor ATE production lines, large-scale multi-channel DAQ industrial monitoring, aerospace distributed measurement platforms.
